Icon Forged Flat-Top Piston & Ring Set : suit Small Block 318ci (.040" / 3.950") Compression Height 1.465" with -4.70cc Valve Reliefs

AU$1,999.00
Expected ship date:When available (call to confirm)
AU$1,999.00
Request Price Match
Add to Wishlist

Overview

You don't need a king's ransom to rule the track, thanks to ICON premium forged piston and ring kits. They deliver high-performance racing pistons crafted from high-strength, primary aluminum alloys and matching performance piston rings. The pistons feature fully machined heads and valve ports, advanced accumulator and mini groove technology, drilled pin holes, triple-wound spiral lock rings, and their proprietary diamond-finished skirts. ICON premium forged pistons can handle the pressure and abuse from the horsepower numbers that your engine produces. If you're ready to give up your kingdom to build more horsepower with a great set of pistons--think again! The ICON premium forged pistons and ring kit best suited for your application will help you reign victorious without spending a lot of cash.



Brand:
Manufacturer's Part Number:
IC847KTD.040
Part Type:
Product Line:
Summit Racing Part Number:
UEM-IC847KTD-040
UPC:
800745178633
Piston Rings Included:
Yes
Bore (in.):
3.950 in.
Bore (mm):
100.330mm
Stroke:
4.000 in.
Rod Length:
6.123 in.
Piston Style:
Step head, with two valve reliefs
Piston Material:
Forged aluminum
Compression Height (in.):
1.465 in.
Piston Head Volume (cc):
+23.00cc
Wrist Pin Style:
Press-fit or floating
Wrist Pin Retainers Included:
Yes
Wrist Pin Included:
Yes
Pin Diameter (in.):
0.984 in.
Piston Ring Thickness:
1/16 in. x 1/16 in. x 3/16 in.
File Fit:
No
Gapless:
No
Top Ring Thickness:
1/16 in.
Top Ring Material:
Ductile iron
Top Ring Facing Material:
Plasma-moly
Second Ring Thickness:
1/16 in.
Second Ring Material:
Iron
Second Ring Facing Material:
Cast iron
Oil Ring Thickness:
3/16 in.
Oil Ring Material:
Stainless steel
Oil Ring Tension:
Standard
Remanufactured:
No
Quantity:
Sold as a set of 8.
Notes:
Step dish design.
